Description
N1F- 3KW 48V DC 110V/120V Hybrid Off-grid Inverter
this is the same model as the EG4 3kw unit.
-
- Pure sine wave,power factor 1.0
- Pvinput 500vdc Max,
- Built-in MPPT 80A,
- Capable of working without a battery (Solar input or grid input only)
- Detachable dust cover for harsh environment
- WiFi remote monitoring optional
- Compatible work with lifepo4 battery via RS485
- Parallel operation with up to 12 units in 1phase/3phase/split phase
- EQ function to optimize battery performance and extend the lifecycle
- 3000W Continuous Output
500 VDC Max Input
Parallel Up To 12 Units
Lightweight
Smaller Footprint Than Other Comparible Models
Overload Protection
Overtemperature Protection
Short Circuit Protection
Power your electronics without worry. The pure sine wave inversion and
power factor correction provides clean, reliable inverter power with low total
harmonic distortion.
Extra high voltage means smaller wire size. Skip the combiner box too!
12 Single Phase | 2 x 6 Split Phase | 3 x 4 Three Phase
ONLY 18lbs! Lift less and power more!
17 inches tall, 11.75 inches wide, and 4 inches deep.
5sec @ 150% Load & 10sec @ 110% – 150% Load
Shield your unit from inclement weather with an extra layer of
overtemperature protection.
Safely power higher amperage loads with peace of mind – the short circuit
feature will protect your unit from overcharging.
