Description
Solar Combiner boxes make connecting multiple solar panels in series and parallel a breeze.
New design!
All your panel wiring troubles made really simple
Built in DC Disconnect.
Built in DC Overcurrent protection.
Built in Lightning protection
Built in fuse protection
Features:
Metal Box (no melting or fire hazard) IP65 Outdoor Weatherproof
Key Lockable
Each Circuit is fused 15A (on both Positive and Negative terminals )
Reverse Polarity Diode Protection
Available in a variety of configurations (4 to 1 , 4 to 2, 6 to 1 , 8 to 2, 8 to 1)
Acrylic face plate cover for full protection (most other suppliers simply ignore this feature) – often hundreds of volts
Surge Protection – 1000V
Specs:
15A per PV Input string
Max 4 x 63A DC Output.
