|Q CELLS Model Number||Q.PEAK DUO L-G5.2 395|
|STC Rating||395.0 Watts|
|Open Circuit Voltage (Voc)||49.00 Volts|
|Short Circuit Current (Isc)||10.24 Amps|
|Power Tolerance||+5W / −0W|
Please review Shipping Policy
The new high-performance module Q.PEAK DUO L-G5.2 395 is the ideal solution for commercial and utility applications thanks to a combination of its innovative cell technology Q.ANTUM and cutting edge cell interconnection. This 1500 V IEC/UL solar module with its 6 busbar cell design ensures superior yields while having a very low LCOE.
Hanwha enhanced low-light performance and the output of Q CELLS across a wide range of temperatures for Q.PEAK DUO solar panels to rival traditional crystalline technologies.
- 144 Q.ANTUM half-cut monocrystalline solar cells by Q CELLS
- Efficient 6-busbar design
- Thermally pre-stressed anti-reflective glass
- Silver anodized aluminum frame
- 4mm² (12AWG) cables with MC4 type connectors
- IP67 weatherproof junction boxes w/ bypass diodes
- Q Cells Q.Antum technology developed in Germany
- This Q.PEAK DUO L-G5.2 395 has a 19.9% module efficiency.
Q.PEAK DUO L-G5.2 from Q CELLS
This state-of-the-art Q.PEAK DUO L-G5.2 solar module from Q CELLS impresses thanks to innovative Q.ANTUM DUO Technology, which enables particularly high performance on a small surface.
Q.ANTUM’s world-record-holding cell concept has now been combined with state-of-the-art circuitry half cells and a six-busbar design, thus achieving outstanding performance under real conditions – both with low-intensity solar radiation as well as on hot, clear summer days.
|Q.ANTUM TECHNOLOGY: LOW LEVELIZED COST OF ELECTRICITY
Q.PEAK DUO L-G5.2 solar panels provide a higher yield per surface area, lower BOS costs, higher power classes, and a record breaking efficiency rate.
|INNOVATIVE ALL-WEATHER TECHNOLOGY
Optimal yields, whatever the weather with excellent low-light and temperature behavior.
|ENDURING HIGH PERFORMANCE
Long-term yield security with Anti LID and Anti PID Technology, Hot-Spot Protect and Traceable Quality Tra.Q™.
|EXTREME WEATHER RATING
High-tech aluminum alloy frame, certified for high snow (5400 Pa) and wind loads (4000 Pa) regarding IEC.
|A RELIABLE INVESTMENT
Inclusive 12-year product warranty and 25-year linear performance guarantee.
|STATE OF THE ART MODULE TECHNOLOGY
Q CELLS Q.ANTUM DUO combines cutting edge cell separation and innovative wiring with Q.ANTUM Technology in Q.PEAK solar panels.
