Sol-Ark SA-12K Pre-Wired Hybrid Solar Inverter System

$5,299.00

SKU: SA-12K Categories: ,

Description

Install Guide & Owners Manual



Features & Benefits:

  • Easy Install, the 12K INVERTER comes with everything you need to install it. Touchscreen Interface
  • AC/DC Coupling, Supports simultaneous DC and AC coupling up to a combined 13kW of PV. Boosts PV energy 10-20% without increasing PV array size and reduces storage inverter costs up to 30%.  (Max AC Coupling = 9600W)
  • Fleet Management, With Sol-Ark’s remote access features and app you are never out of touch to quickly repair or adjust any system without being on site.
  • Grid Tied Mode

Specifications:

  • AC Voltage: 120/240V split phase
  • AC Frequency: 60/50 Hz
  • Max Continuous AC Output Power:12,000W
  • 2 x Independent MPPT Inputs
  • MPPT Voltage Range: 150-425V   (Max Voc 500V @18 A, 450V @20 A)
  • Max Input Current: 18Amp (per mppt), Starting Voltage = 125V
  • Inverter Efficiency: 96.0%
  • Listings & Certifications:UL1741-2010/2018, IEEE1547a-2003/2014, FCC 15 class B
  • Weight: 78. lbs
  • Dimensions (H x W x D): 30.0″ x 18.30″ x 10.00″
  • 10 Year Standard Warranty (Verified by HALT Testing)







Additional information

Weight 96 lbs
Dimensions 35 × 24 × 15 in
