Sol-Ark SA-15K Hybrid Solar Battery System

$8,250.00

SKU: SA-15K-1 Categories: ,

Description

Install Guide & Owners Manual

Battery Communication Integration



Features & Benefits:

  • Easy Install, the 15K INVERTER comes with everything you need to install it. Touchscreen Interface
  • Parallel stacking up to 12 units – Massive 144kW system from battery power, 180kW with Solar and Battery
  • AC/DC Coupling, Supports simultaneous DC and AC coupling up to a combined 19.5kW of PV. Boosts PV energy 10-20% without increasing PV array size and reduces storage inverter costs up to 30%. (Max AC Coupled PV = 19,200W)
  • Fleet Management, With Sol-Ark’s remote access features and app you are never out of touch to quickly repair or adjust any system without being on site.
  • Grid Tied Mode
  • Idle Consumption, only 90W

Specifications:

  • AC Voltage: 120/240V split phase and 208V 2 phase
  • AC Frequency: 60/50 Hz
  • Max Continuous AC Output Power:15,000W (with Batt & PV Input = 15kW, battery input only = 12kW)
  • 3 x Independent MPPT Charge Controllers
  • MPPT Voltage Range: 125-425V ( Max Voc = 500V @26A)
  • Max Input Current: 26Amp (per mppt)
  • Inverter Efficiency: 96.0%
  • Listings & Certifications:UL1741-2010/2018, IEEE1547a-2003/2014, FCC 15 class B
  • Weight: 135. lbs
  • Dimensions (H x W x D): 31.8″ x 18.30″ x 10.9″
  • 10 Year Standard Warranty (as verified by HALT Testing)

Protections & Certifications

  • Electronics Certified Safety by SGS Labs to NEC & UL Specs NEC 690.4B & NEC 705.4/6 -“Yes”
  • Grid Sell Back UL17412010/2018, IEEE1547a2003/2014, FCC 15 Class B, UL1741SB, CA Rule 21, HECO Rule 14H = “Yes”
  • PV DC Disconnect Switch NEC 240.15 Integrated
  • Ground Fault Detection NEC 690.5 Integrated
  • PV Rapid Shutdown Control NEC 690.12 Integrated
  • PV Arc Fault Detection NEC 690.11 Integrated
  • PV Input Lightning Protection Integrated
  • PV String Input Reverse Polarity Protection Integrated
  • AC Output Breakers 200A Integrated
  • 200A x 2 Battery Breaker / Disconnect Integrated
  • Surge Protection DC Type II / AC Type II





Additional information

Weight 135 lbs
Dimensions 31.8 × 18.3 × 10.9 in
