Description
These panels are on pallets of 30 pcs, so this is your opportunity to get a top panel at a bottom price.
Cost about $140 per panel (compare on the internet at $293 + each) (Over $8000 per pallet)
PDF.
Enhanced reliability
· Up to 50% lower degradationLID / LeTID mitigation
· Lower hot spot temperature
· Better shading tolerance
- 12 years enhanced product warranty on materials and workmanship
30 years linear power output warrantyAccording to the applicable Canadian Solar Limited Warranty Statement.
Solar Panel Tech Specs
| Specification: | CS6W-530MB-AG |
| Peak Power Watts (PMAX) | 530W |
| Power Tolerance (PMAX) | 0 ~ +5W |
| Maximum Power Voltage (VMPP) | 41.3V |
| Maximum Power Current (IMPP) | 13.08A |
| Open Circuit Voltage (VOC) | 49.2V |
| Short Circuit Current (ISC) | 13.9A |
| STC Efficiency | 21.0% |
| Solar Cells | Monocrystalline |
| Cell Count | 144 |
| Nominal Operating Cell Temperature (NOCT) | 41°C (±3°C) |
| Temperature Coefficient of PMAX | -0.34%/°C |
| Temperature Coefficient of VOC | -0.26%/°C |
| Temperature Coefficient of ISC | 0.05%/°C |
| Operational Temperature | -40°C ~ +85°C |
| Maximum System Voltage | 1500VDC |
| Max Series Fuse Rating | 30A |
| Glass | 2.0 mm heat strengthened front / back glass |
| Frame | 35mm anodized aluminum alloy |
| Backsheet | 0.08″ (2.0mm) heat-strengthened glass (white grid glass) |
| J-Box | IP 68 rated |
| Connectors | Staubli MC4 |
| Dimensions | 2266 ˣ 1134 ˣ 35 mm (89.2 ˣ 44.6 ˣ 1.38 in) |
| Weight | 32.2 kg (71.0 lbs) |
Bifacial Gain
CS6W-530MB-AG
0% 540 W 41.3 V 13.08 A 49.2 V 13.90 A 21.0%
0% 540 W 41.3 V 13.08 A 49.2 V 13.90 A 21.0%
5% 567 W 41.3 V 13.73 A 49.2 V 14.60 A 22.1%
10% 594 W 41.3 V 14.39 A 49.2 V 15.29 A 23.1%
20% 648 W 41.3 V 15.70 A 49.2 V 16.68 A 25.2%
