Ecoworthy / MHT 10KW 48V Solar Inverter 120V/220V Split Phase 200A Charger
Ecoworthy / MHT 10KW 48V Solar Inverter 120V/220V Split Phase 200A Charger - Image 2
Ecoworthy / MHT 10KW 48V Solar Inverter 120V/220V Split Phase 200A Charger - Image 3

Ecoworthy / MHT 10KW 48V Solar Inverter 120V/220V Split Phase 200A Charger

$1,499.00

18 in stock

Category:

Description

Model :

MHT48-10K-U

10kW  120/240VAC split phase, 50/60Hz Off Grid Solar Inverter.

2 x MPPT Voltage range 120 to 450V DC



Three Output Modes: Grid-connected power generation, anti-reverse-current, or off-grid output mode can be configured when function is enabled.
✓
Smart Monitoring: Supports host computer and APP cloud communication for real-time operating data, status display, and parameter modification.
✓
Four Charging Modes: Mains priority, solar priority, mains solar hybrid, and solar only charging available.
✓
Emergency Function: Supports battery-free output, PV-only start and load, including a battery activation function for home use.
✓
Parallel Capability: Flexibly combine up to 9 machines in parallel to output single-phase or three-phase AC voltage.
✓
Advanced Protection: Sound hardware and software protection functions that display specific fault types for easy troubleshooting.

Frequently Asked Questions

What charging modes does the MHT inverter support?
The inverter supports four charging modes: Only Solar, Mains Priority, Solar Priority, and Mains & Solar hybrid charging to suit various energy needs.
Can this solar inverter work without a battery?
Yes, it supports battery-free output where the system can start and run loads using only PV (Solar) power, including a dedicated battery activation function.
How many units can be connected in parallel?
The system is highly scalable and can be flexibly combined to achieve up to 9 units in parallel, supporting both single-phase and three-phase AC output.
What types of batteries are compatible with the system?
The MHT series is compatible with Lithium-ion batteries, Lead-acid batteries, and allows for User Defined battery parameters.
Is remote monitoring available?
Yes, the system supports real-time monitoring through a host computer and a dedicated APP cloud, allowing users to view operating data and modify parameters remotely.
What kind of protection does the inverter offer?
It includes comprehensive hardware and software protection against short circuits, overloads, and faults, with specific fault type displays for easy maintenance.

Technical Parameters

MODEL MHT48-5500-U MHT48-10K-U
INVERTER OUTPUT
Rated output power (W) 10000
Rated output power (VA) 10000
Maximum Peak Power (W) 15000
Load Capacity with Motors 6HP
Rated AC Output 120Vac, 50/60Hz 120/240Vac (single/split phase), 50/60Hz
Output Voltage Waveform Pure Sine Wave
Parallel Capacity Up to 9 channels
BATTERY
Battery Type Lithium / Lead-acid / User Defined
Rated Battery Voltage 48Vdc
Max. Hybrid Charging Current 200A
PV CHARGING
MPPT Quantity 1 3
Max. PV array power 5500W 5500W+5500W
Max. PV input current 22A 22A+22A
MPPT Voltage Range 120-450V
SPECIFICATIONS
Dimensions (W*D*H mm) 350*130*455 445*130*630
Weight (kg) 12 27
IP Protection IP20
Noise <60dB
Communication Interface RS485 / CAN / USB / Dry contact / WIFI / GPRS

Additional information

Weight 65 lbs
Dimensions 32 × 20 × 9 in

User Manual

User-Manual-of-GST48-Series-Single-phase-Off-Grid-Inverter
